DS7400XiV4-EXP | Wireless Reference Guide | 5.0 Adding Keyfobs EN | 21
Bosch Security Systems | 6/05 | 4998154962B
Table 30: Address 0483 to 0538, Zone-to-Address Cross Reference
Zones Address Zones Address Zones Address
Zones 137 & 138 0483 Zones 175 & 176 0502 Zones 213 & 214 0521
Zones 139 & 140 0484 Zones 177 & 178 0503 Zones 215 & 216 0522
Zones 141 & 142 0485 Zones 179 & 180 0504 Zones 217 & 218 0523
Zones 143 & 144 0486 Zones 181 & 182 0505 Zones 219 & 220 0524
Zones 145 & 146 0487 Zones 183 & 184 0506 Zones 221 & 222 0525
Zones 147 & 148 0488 Zones 185 & 186 0507 Zones 223 & 224 0526
Zones 149 & 150 0489 Zones 187 & 188 0508 Zones 225 & 226 0527
Zones 151 & 152 0490 Zones 189 & 190 0509 Zones 227 & 228 0528
Zones 153 & 154 0491 Zones 191 & 192 0510 Zones 229 & 230 0529
Zones 155 & 156 0492 Zones 193 & 194 0511 Zones 231 & 232 0530
Zones 157 & 158 0493 Zones 195 & 196 0512 Zones 233 & 234 0531
Zones 159 & 160 0494 Zones 197 & 198 0513 Zones 235 & 236 0532
Zones 161 & 162 0495 Zones 199 & 200 0514 Zones 237 & 238 0533
Zones 163 & 164 0496 Zones 201 & 202 0515 Zones 239 & 240 0534
Zones 165 & 166 0497 Zones 203 & 204 0516 Zones 241 & 242 0535
Zones 167 & 168 0498 Zones 205 & 206 0517 Zones 243 & 244 0536
Zones 169 & 170 0499 Zones 207 & 208 0518 Zones 245 & 246 0537
Zones 171 & 172 0500 Zones 209 & 210 0519 Zones 247 & 248 0538
Zones 173 & 174 0501 Zones 211 & 212 0520
5.2 Program a Zone
Zone Programming (Program Addresses 0167 to 0278) is different when programming keyfobs. Data
Digit 1 is always 0, and Data Digit 2 can only be 1, 2, 3, or 4.
Keyfob function programming starts at Program Address 0167.
Hint: Zone number + 30 = The Program Address (for example: Zone 137 + 30 = Program Address 0167)
• Addresses: 0167 to 0278
• Data Digit:
• Data Digit 1: Must = 0
• Data Digit 2: ____ (refer to Table 31)
• Selections: 0 to 4
Table 31: Zone Programming (Addresses 0167 to 0278,
Data Digit 2)
Selections
for Data
Digit 2
Select Options 1 2 3 4
Single Partition No Force Arming Allowed
•
Single Partition Force Arming is Allowed
•
All Partitions No Force Arming Allowed
•
All Partitions Force Arming is Allowed
•
