DS7400XiV4-EXP | Wireless Reference Guide | 4.0 Adding RF3341 Keypads EN | 17
Bosch Security Systems | 6/05 | 4998154962B
4.6 Program the On-Board Outputs (Optional)
The operation of the Option Key is the same on all keypads that are assigned to the same area.
The RF3341 Keypad has an Option key that can be programmed to drive any of the control panel’s three outputs,
or any of the 24 custom programmable outputs. Refer to Table 22.
• Addresses: 2734 to 2736
• Data Digits:
• Data Digit 1: Must = *0 for outputs driven by a wireless keypad
• Data Digit 2: ____ (refer to Table 21)
• Selections: 0 to 9; *0, *1, *3 (hexadecimal values that display as A , B, and D respectively at the keypads)
Table 21: Address 2734 to 2736, Data Digit 2
When Data Digit 1 = *0
Options RF3341 Value
Disabled 0
Momentary Option Key 1
Toggle Option Key 2
Table 22: Address 2734 to 2736 Defaults
Output Address Default
Alarm 2734 6 3
Programmable Output 1 2735 3 3
Programmable Output 2 2736 2 3
