42 en | Planning Aspirating Smoke Detector
2018.04 | 2.0 | F.01U.130.926 Operation Guide Bosch Sicherheitssysteme GmbH
Without any other pipe accessories
Number of air sampling openings
Pipe
shape
U
Fans
1 2 3 4 5 6 7 8 9 10 11 12 … 32
I 6.9 77 77 77 77 77 77 77 77 76 l
[m]
≥9 100 100 100 100 100 100 100 100 100 100 100 100
U 6.9 120 120 120 120 120 120 120 120 120 120 120 120
≥9 150 150 150 150 150 150 150 150 150 150 150 150
M 6.9 170 170 170 170 170 170 170 170 170 170 170 170
≥9 180 180 180 180 180 180 180 180 180 180 180 180
2 x U 6.9 180 180 180 180 180 180 180 180 180 180 180 180
≥9 200 200 200 200 200 200 200 200 200 200 200 200
4 x U (1
DM)
6.9
≥9 300 300 300 300 300 300 300 300 300 300 300 300 300
With water separator
Number of air sampling openings
Pipe
shape
U
Fans
1 2 3 4 5 6 7 8 9 10 11 12 … 32
I 6.9 60 60 60 60 60 60 60 l [m]
≥9 80 80 80 80 80 80 80 80 80 80
U 6.9 110 110 110 110 110 110 110 110 110 110 110 110
≥9 110 110 110 110 110 110 110 110 110 110 110 110
M 6.9 110 110 110 110 110 110 110 110 110 110 110 110
≥9 160 160 160 160 160 160 160 160 160 160 160 160
2 x U 6.9 140 140 140 140 140 140 140 140 140 140 140 140
≥9 160 160 160 160 160 160 160 160 160 160 160 160
