MAP 5000 Introduction | en 9
Bosch Sicherheitssysteme GmbH Installation manual 2016.06 | 17 | F.01U.168.332
Key Description
1 Current limitation
2 4-wire connection, take into account cable length
3 3-wire connection to the next power supply segment
4 Short-time current limitation to 3.2 A per output A / B
5 Current limitation to 1.6 A between internal and external BDB
Remote operation with ICP-MAP0120 expansion enclosure
Figure1.4: 2 LSN modules with up to 4 control centers
Figure1.5: Up to 8 control centers
Key Description
1 Current limitation
2 4-wire connection, take into account cable length, refer to , page 10
3 3-wire connection to the next power supply segment
4 Short-time current limitation to 3.2 A per output A / B
Cable length
The maximum number of control centers that can be supplied by one power supply depends
greatly on the length and diameter of the cable used.
