33 Axial piston variable pump | A4VSO Series 10, 11 and 30
Dimensions, through drive
Flange ISO 3019-2 (metric) Hub forsplined shaft
2)
Code
Diameter Symbol Diameter 40 71 125 180 250 355 500
224-4
N60×2×28×8H
– – – – – –
●
K35
N60×2×28×8H
– – – –
● ●
– U35
● = Available ○ = On request ‒ = Not available
▼ 224-4 ▼ 224-4
A1 (to mounting flange)
Section M-N
N
M
ø224
+0.10
+0.03
1)
45º
A7
A4
A3
A2
ø280
A1 (to mounting flange)
Section M-N
N
M
ø224
+0.10
+0.03
1)
45º
A7
A4
A3 A2
ø280
K35 NG A1 A2 A3 A4 A7
3)
U35 NG A1 A2 A3 A4 A7
3)
500 541 12.5 74 9 M20; 36 deep 250 469 12.5 75 9 M20; 37 deep
355 498 12.5 75 9 M20; 37 deep
Notice
All attachment pumps must match the ATEX classification
for the application in question.
1) Mounting bolts and O-ring seal are included in the scope of
delivery
2) Splined hub according to DIN5480
3) Thread according to DIN13, see Part I for maximum tightening
torques.
