29 Axial piston variable pump | A4VSO Series 10, 11 and 30
Dimensions, GE control, NG 71, 125 and 180
Dimensions [mm]
Dimensions, GE control, NG 71, 125 and 180
GE – Rod system control (clockwise rotation, counter-clockwise swivel direction)
L
R(L)
M
2
B
B
1
M
1
15° 15°
0
D5
D2
0
M14 x 1.5
D3
D1 D4
20
Control stroke up to V
g max
(atV
g min
)
Further dimensions and ports in respective sizes can be found in this manual.
Size D1 D2 D3 D4 D5 Ports M
1
and M
2
State
71 180 17.1 108 149 166 – –
125 178 20.7 132 177 203 M14 × 1.5 plugged
180 178 20.7 132 177 203 M14 × 1.5 plugged
