Installation 41/72
RE 92050-01-X-B1/2019.08.23, Axial piston variable pump A4VSO, BoschRexrothAG
Fig. 11: Removing transport protection
1 Protective covers
2 Protective plugs/threaded plugs
3 For version with through drive,
flangecover and fixing screws
Ports intended for connecting lines come with protective plugs and/orthreaded
plugs, which serve astransport protection. Make sure all ports required for
functional operation are connected (see Table 15 "Ports A4VSO" on page43).
Failure todo socould lead tomalfunctions ordamage. If aport isnot being used,
plug itwith athreaded plug since theprotective plugs are not pressure-resistant.
The setting screws are protected against unintentional adjustment by caps.
Adjusting the setting screws will render the warranty void. If you need to change
settings, contact your BoschRexrothService partner; see chapter 10.5 "Repair"
on page 61 for an address.
3. For versions with through drive, install theauxiliary pump according tothe pump
manufacturer's instructions.
7.4.8 Hydraulically connecting theaxial piston unit
NOTICE
Insufficient suction pressure!
Generally, aminimum permissible suction pressure atportS isspecified for axial
piston pumps inall installation positions. If thepressure atportS drops below
thespecified values, damage may occur which may lead tothe axial piston pump
being damaged beyond repair!
▶ Make sure thenecessary suction pressure ismaintained. This isinfluenced by:
–The piping (e.g. suction cross-section, pipe diameter, length ofsuction line)
–The position ofthereservoir
–The viscosity ofthehydraulic fluid
–A filter element orcheck valve inthe suction line (check thelevel
ofcontamination ofthefilter element regularly)
The machine/system manufacturer isresponsible for dimensioning ofthelines.
Connect theaxial piston unit tothe rest ofthehydraulic system inaccordance with
thehydraulic circuit diagram ofthemachine/system manufacturer.
The ports and fastening threads are designed forthe maximum pressure specified
inthe datasheet. The machine/system manufacturer isrequired toensure that
theconnecting elements and lines correspond tothe specified application
conditions (pressure, flow, hydraulic fluid, temperature) with thenecessary
safetyfactors.
