Hydraulics Bosch Rexroth AGRE 30110/05.12 VSPA2-1-2X
5/10
Block circuit diagram / connection allocation; VT-VSPA2-1-2X/V0/T5
Com. value 4 Com. value 3 Com. value 2 Com. value 1 Ramp time external Com. value 5 ± 10 V Com. value 6 4-20 mA Com. value call-ups Inversion Enable Operating voltage
Reserved
Internal com. value
Reserved
Solenoid b
Solenoid a
Actual value Reserved
Operational +10 V / 25 mA
–10 V / 25 mA
Measurement signal
M0 System earth
UP/DOWN
Enable
Enable
Fault recognition
Controller
Measuring points
Ramp on/off
Ramp call-ups
4-Quadrant operation
1 Power supply 2 Differential input 3 Current input 4
Com. value selection logic
5 Zero point adjustment 6 Com. value summation
7 Com. value inversion 8 Enable function 9 Ramp generator 10
Characteristic curve generator
11 Amplitude limiter 12 Com. value output
13 Clock generator 14 Actual current output 15 Current controller 16 Current output stage 17 Fault recognition 18
Measuring point switchover
19 Ramp time selection logic ok1 enable Output stage ok2 monitoring Amplifier
