6/10 Bosch Rexroth AG Hydraulics VSPA2-1-2X RE 30110/05.12
Operating voltage U
B
24 VDC + 40% – 20%
Functional range:
– Upper limiting value U
B
(t)
max
35 V
– Lower limiting value U
B
(t)
min
18 V
Power consumption P
S
< 50 VA
Current consumption I < 2A
Fuse I
S
2 A medium slow, replacable
Inputs:
– Analog
• Com. value 1 to 4 (potentiometer inputs) U
e
0 to ±10 V; R
e
> 100 kΩ (ref. is M0)
• Com. value 5 (differential input) U
e
0 to ±10 V; R
e
> 50 kΩ
• Com. value 6 (current input) I
e
4 to 20 mA; load R
B
= 100 Ω
• External ramp time U
e
0 to + 10 V; R
e
= 10 kΩ (raised internally to +15 V; ref. is M0)
– Digital
• Command value call-ups U 8.5 V to U
B
–> call-up actuated; R
e
> 100 kΩ
U 0 to 6.5 V –> no call-up; R
e
> 100 kΩ
• Ramp call-up (option T5) U 8.5 V to U
B
–> call-up actuated; R
e
> 100 kΩ
U 0 to 6.5 V –> no call-up; R
e
> 100 kΩ
• Quadrant recognision U 8.5 V to U
B
–> ON; R
e
> 100 kΩ
U 0 to 6.5 V –> OFF; R
e
> 100 kΩ
• Command value inversion U 8.5 V to U
B
–> ON; R
e
> 100 kΩ
U 0 to 6.5 V –> OFF; R
e
> 100 kΩ
• Enable U 8.5 V to U
B
–> ON; R
e
> 100 kΩ
U 0 to 6.5 V –> OFF; R
e
> 100 kΩ
• Ramp U 8.5 V to U
B
–> ON; R
e
> 100 kΩ
U 0 to 6.5 V –> OFF; R
e
> 100 kΩ
Setting ranges
– Zero compensation (potentiometer „Zw“) ±30%
– Command value (potentiometers „w1“ to „w4“) 0% to 110%
– Ramp times (potentiometers „t1“ to „t5“) 20 ms to 5 s; switchable 0.2 to 50 s
– Jump height (potentiometers „S+“ and „S–“) 0% to 50%
– Amplitude attenuation (potentiometers „G+“ and „G–“) 0% to 110% (valid when setting the jump height from 0%)
Outputs
– Command value signal U ±10 V ± 2 %; I
max
= 2 mA
– Actual value signal U
±2.5 V ± 2 %; I
max
= 2 mA (mV mA)
– Measuring point signal (option 5) U ±10 V ± 2 %; I
max
= 2 mA
– Operational U > 16 V; 50 mA (with a fault: U < 1 V; R
i
= 10 kΩ)
– Controlled voltages U ±10 V ± 2 %; 25 mA; short circuit-proof
– Current output stage I 0 to 2.5 A; short circuit-proof
– Measurement sockets Command value signal
Actual value signal
±10 V ± 2 %; I
max
= 2 mA
±2.5 V ± 2 %; I
max
= 2 mA (mV mA)
Technical data (for applications outside these parameters, please consult us!)
