Bosch Rexroth VT-VSPA2-1-2X/V0/T5 User Manual

VSPA2
-1
t
Zw
w1
w2
w3
w4
t
S+ Gw- S-
wI
Gw+
J7
J5
J1
f
J4
J6
J3
T
J2
J10
J9
J8
REXROTH
8/10 Bosch Rexroth AG Hydraulics VSPA2-1-2X RE 30110/05.12
LED displays:
Operational (green)
Enable (yellow)
–1
External inversion
Potentiometer (partially with LED display):
Zw Zero point alignment adjustable on the board:
w1 Command value 1 Gw+
Amplitude attenuation for positive command values
w2 Command value 2 Gw– Amplitude attenuation for negative command values
w3 Command value 3 S+ Jump heights for a positive direction
w4 Command value 4 S– Jump heights for a negative direction
t Ramp time f Clock frequency output stage
Adjusting the locked potentiometers invalidates any guarantee claims!
Measurement sockets:
I, w, t Measurement signal
⊥ Measurement zero
Display / adjustment element T1
J3 ramp time
0.2 to 50 sec.
0.02 to 5 sec.
•
J4 Jump function
Off
On
•
J1 inversion
Inverted
Not inverted
•
J8, J9 jump height J8 J9
4WRA6 and 10…2X
4WRZ…7X, 3DREP…2X
•
J5, J6 clock frequency J5 J6
4WRA6…2X
4WRA10…2X
Universal,
4WRZ…7X
3DREP…2X
J2 ramp function
Off
On
•
J7 max. current setting
4WRZ…7X,
3DREP…2X
•
4WRA…2X
•=
Factory jumper setting
=
Jumper closed
=
Jumper open
