Bosch RTM 430 - Assembly and Electrical Wiring; 1.1 Assembly;Dismantling before FD 5;92

44
BOSCH
1
1
2
2
459600/1Ha
9
3
4
7
1
6
3
5
2
8
10
11
1. Assembly / dismantling and
electrical wiring
1.1 Assembly / Dismantling before FD 5/92 (Fig.1)
Fig. 1, Assembly / dismantling
1 Measurement chamber
2 Motherboard/processor board
3 Heater air curtain
4 Emitter
5 Receiver
6 Valve
7 Temperature sensor, measurement chamber
8 LED, power supply RTM
9 Ventilator
10 Battery
11 Temperature sensor, exhaust gas
