Figure 7
Front features
of
the media
center
Front
door-
Make sure you have
enough room to lift this door.
\
Disc tray - Make sure nothing blocks this
CO/OVD tray
as
it slides open.
Display window - Make sure you can see
this information while using your system.
®
The
IR
Emitter, which enables certain
remote control operation,
is
located here.
Connecting the speakers to the Acoustimass® module
A CAUTION: Before you make anyconnections, be sure that the media center, the Acoustimass
module,
and
any
additional equipment are
not
connected
to
AC
power.
Your system may have Jewel
Cube®
speakers (image A on the left), which use a plug-in cable
connect, or cube array or single cube speakers (images 8 and C respectively,) which use a
two-wire cable.
L1FESTYLE®
DVD systems include five speakers.
Connecting
the
plug-in cable
to
Jewel
Cube®
speakers
)
Note:
If
your
system has cube
or
cube array speakers,
foJ/ow
the instructions in "Making the
two-wire connections for cube
or
cube array speakers" on page
13.
The positive and negative wIres
of
the plug-in cable are properly oriented for polarity and the
plug
is
designed to fit only one way into the jack.
1.
Match the correct cable to the corresponding speaker location:
• Front speaker cables have blue RCA connectors on one end and speaker plugs at the
other end with L (left), R (right), or C (center) markings.
• Surround speaker cables have orange RCA connectors at one end and speaker plugs
at the other end with L (left) or R (right) markings.
12
