Connecting
the
antennas
You
should connect the additional AM and
FM
antennas, included with your system,
to
the
rear panel
of
the media center (Figure 12).
FM
dipole antenna lead
AM antenna lead
Figure
12
Connections for the
AM
and FM antennas
J
Note:
The
FM
jack
(75 ohm) can be used with an outdoor antenna.
To
do this, consult a qual-
ified installer. Follow all safety instructions supplied with the antenna.
A.
CAUTION: Do
not
attempt
to
connect a television cable
to
the FM antenna jack.
Connecting
the
FM
antenna
Plug the connector on the
FM
dipole antenna lead into the
FM
antenna jack. Spread out the
antenna arms. Change the orientation of the antenna arms
to
get optimum
FM
reception.
Place the antenna as far from the media center and other components as possible.
Connecting
the
AM
antenna
J
Note:
To
mount the
AM
antenna on a
wall,
follow the instructions enclosed with
the
antenna.
1.
Plug the connector on the AM antenna lead into the AM antenna jack.
2.
Stand the loop antenna on the base, following the instructions enclosed with the AM
antenna.
3.
Move the AM loop antenna
as
far as possible, at least 20 inches
(50
cm), from the media
center, and at least 2 feet
(60
cm) from the Acoustimass® module. Experiment with the
orientation
of
the loop for optimum AM reception.
J
Note:
AM
radio reception may be adversely affected
by
your television. For best
AM
recep-
tion, turn the television off.
Connecting
to a
cable
radio
provider
Some cable
TV
providers make
FM
radio signals available through the cable service
to
your
home. This connection
is
made
to
the
FM
antenna jack
on
the back panel
of
the media cen-
ter.
To
connect to this service, contact your cable
TV
provider for assistance.
J
Note:
Make sure that the cable radio installation includes a signal splitter so that only the FM
radio band, not the cable TV band,
is
received
by
the media center.
If
necessary, contact a
qualified installer.
16
