Figure 9
Connecting the two-wire
cable to cube speakers
2.
Connect the wire end of one speaker cable
to
the terminals on the rear
of
the matching
speaker.
• Press the terminal tab
on
the back of the speaker and insert the marked wire
(+)
into the
red terminal and the plain wire (-) into the black terminal.
• Release the tab
to
secure the wire. Repeat this step for each of the five speakers.
Left, Right, or Center
printed on the red
collar on
(+)
wire
3.
Connect each cable to the corresponding jack on the Acoustimass® module (Figure
10).
• Plug the blue connectors into the matching left front, center, and right front jacks.
• Plug the orange connectors into the matching left surround and right surround jacks.
Figure
10
Speaker connections
to
the
Acoustimass module
Left
Front speakers
Center Right
Surround speakers
Left Right
14
Acoustimass module connector panel
) Note:
You
may find it more convenient
to
place the Acoustimass module upside down while
making connections. When done, place it on
any
of
its sides
but
not on either end
or
top.
