5.4 PRESET Button – Dual Mono Operation
Note: If you only have a connection plugged into
Input 1, the signal will only pass through Outputs 1
and 2.
If you only have a signal plugged into Input 2, the
signal will only pass through Outputs 3 and 4.
If you want to send the same audio information to
both of the PANARAY system digital controller’s
inputs, you can achieve this in two ways:
1. From your mixer set all of your pan controls to
center position (this will sum your information to
mono). Next plug the left and right outputs from
your mixer into CH1 and CH2 on the PANARAY
system digital controller.
2. From a mono source use a Y-cable to send the
same information into CH1 and Ch2 on the
PANARAY system digital controller.
CH1 Input
The top of the display shows the preset name that
will be processed by the CH1 input. This signal will
be routed to Outputs CH1 and CH2. If this is a full-
range preset, the same EQ will be applied to
Outputs CH1 and CH2. If this preset consists of a
mid-high device with a bass loudspeaker, the mid-
high frequencies will be routed to Output CH1 and
the low frequencies will be routed to Output CH2.
CH2 Input
The bottom of the display shows the preset that is
processed by the CH2 input. This signal will be
routed to Outputs CH3 and CH4. If this is a full-
range preset, the same EQ will be applied to
Outputs CH3 and CH4. If this preset consists of a
mid-high device with a bass loudspeaker, the mid-
high frequencies will be routed to Output CH3 and
the low frequencies will be routed to Output CH4.
Loading presets from
Dual Mono mode:
Dual Mono: When the PANARAY
®
system digital
controller is used in Dual Mono mode, the
EQ/Crossover blocks process each input indepen-
dently, allowing you to run two different speaker
EQs.
To access Dual Mono mode, press the PRESET
button. Then press the Arrow DOWN button until
you see the following display:
1: .402I
2: 402I
The period (.) next to the preset name indicates
that the Encoder can change the preset. To select
between 1 and 2, use the Arrow UP/Arrow Down
buttons.
22
