Bose PANARAY System User Manual

54
Sample Rate
44.1kHz
Analog Inputs:
Connectors
(2) XLR balanced
Impedance balanced
21kΩ
Input level
Maximum: +18dBu
Minimum: 0dBu
Sensitivity
@9dB headroom: -12dBu to +9dBu
A to D conversion
24 bit, 128x oversampling bitstream
Dynamic range
95dB typ, 20Hz - 20kHz
THD
Typ < 92dB (0.0025%) @ 1kHz
Frequency response
20Hz to 20kHz, +0/-0.1dB
Crosstalk
< -100dB, 20Hz to 20kHz
Analog Outputs:
Connectors
(4) XLR balanced
Impedance balanced
40Ω
Maximum output level
+18dBu (balanced)
Output ranges
Balanced 20/14/8/2dBu
D to A conversion
24 bit, 128x oversampling bitstream
D to A Delay
0.63ms @ 44.1kHz
Dynamic range
100dB typ 20Hz - 20kHz
THD
Typ < 94dB (0.002%) @ 1kHz +20dBu output
Frequency response
20Hz to 20kHz: +0/-0.5dB
Crosstalk
< -95dB, 20Hz to 20kHz
Environment:
Operating temperature
32˚F to 122˚F (0˚C to 50˚C)
Storage temperature
-22˚F to 167˚F (-30˚C to 70˚C)
Humidity
Maximum 90% non-condensing
Control interface:
Finish
Black anodized aluminum front-plated and painted
steel chassis
Mains voltage
100 to 240VAC, 50Hz to 60Hz (auto switching)
Power consumption
< 15W
14.0 Technical Information
