24
6.0 DELAY Button
Pressing the DELAY button provides access to four
independent output delays. There is a single delay
line available on each of the controller’s four out-
puts. The delay function is always available regard-
less of the mode of operation.
Each delay provides up to 200ms of delay on each
of the four outputs (increments in 0.02ms intervals).
Use the Arrow UP and Arrow DOWN buttons to
navigate through the parameters, and use the
Encoder wheel to select parameter values.
The four output delays have the following
parameters:
Delay On/Off: Bypasses delay
Delay Time: Adjustable in 0.02ms increments
retemaraPyaleDegnaR
1yaleDffO/nO
2yaleDffO/nO
3yaleDffO/nO
4yaleDffO/nO
1emityaleDsm00.002-sm00.0
2emityaleDsm00.002-sm00.0
3emityaleDsm00.002-sm00.0
4emityaleDsm00.002-sm00.0
S
TANDB
Y
Stereo Bank
802 Full Range
-dB
L
R
40 24 18 12 6 0 O
PA NA RAY SYSTEM DIGITAL CONTROLLER
PRESET
LIMITER
UTILITY
DELAY
INPUT METER TPM
DELAY
