Multi-DM™ User Manual Section 4 - Introduction
BMC Document Number: DOC-0009 Rev. 5.2 Page 7
Every deformable mirror can be safely actuated to the maximum stroke specified.
No safety factor is necessary to safeguard proper function of the mirror.
Throughout this document, unless otherwise noted, all references to,
and descriptions of, the Multi-DM also apply to the Multi-SLM version.
4.3.2 Multi Driver
Computer Interface: USB 2.0
Max Frame Rate: 8 kHz (125 μs USB packet size)
Voltage for Max Deflection Up to 300V (device-specific)
Slew Rate 2V/μs
Slew Time to Max Deflection
Up to 150 μs (device-specific based on Max Voltage)
Power Requirements: Chassis requires 24V, 2A Max
which is supplied by AC\DC converter requiring
100-240 Volt, 1.6 A, 50-60 Hz
Output Voltage Limit In hardware to ensure safe mirror operation
Driver Voltage limits are specific to the specified Boston Micromachines DM.
If multiple systems are ordered, DO NOT mix and match DMs and driver electronics.
