11 Technical specifications
84 ARC 300 / ARC 350 Operating manual 900-350_IFU_V2.6_10296-S13-20100111-EN
Setting Program
GastroCUT Pap 22
ARC350GCPap_SE_10011_1
0
10
20
30
40
50
60
70
10
100
1000
10000
R [Ohm]
P [W]
Coag Phase Blend 9
Coag Phase Blend 8
Coag Phase Blend 7
Coag Phase Blend 6
Coag Phase Blend 5
Coag Phase Blend 4
Coag Phase Blend 2,3
Coag Phase Blend 0,1
Measurement of resistances
• Diagram of power output P [W] as a
function of the load resistance R [Ω] for
the setting “GastroCUT Pap”
“Blend 0-9” during the Coag phase
ARC350GCPap_SE_100111_3
0
100
200
300
400
500
600
10
100
1000
10000
R [Ohm]
P [W]
Measurement of resistances
• Diagram of power output P [W] as a
function of the load resistance R [Ω] for
the setting “GastroCUT Pap” during the
Cut phase
ARC350GCPap_SE_100111_2
0
10
20
30
40
50
60
70
0123456789
Blend
P [W]
Coag Phase
Cut Phase = 520 W
• Diagram of power output P [W] as a
function of the “Blend” setting for
“GastroCUT Pap”
Blend
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
• Diagram of HF output voltage U [Vp] as
a function of the “GastroCUT Pap”
“Blend 0-9” (idle mode)
The short-term peak power exceeds 400 W. However, this is still
permissible since the mean value from 1 second is below 400 W.
