11 Technical specifications
900-350_IFU_V2.6_10296-S13-20100111-EN ARC 300 / ARC 350 Operating manual 99
Setting Program
Local Anesthesia COAG 8
ARC350SCFC_SE_080124_1
0
5
10
15
20
25
30
35
40
45
50
10 100 1000 10000
P [W]
Local
Anesthesia
P=20W
Local
Anesthesia
P=40W
Measurement of resistances
• Diagram of power output P [W] as a
function of the load resistance R [Ω] for
the setting "Local Anesthesia COAG" =
40 W/20 W
ARC350SCFC_SE_080124_2
0
5
10
15
25
35
20
30
40
0 5 10 15 20 30
3525 40
displayed value
P [W]
• Diagram of power output P [W] as a
function of the “Local Anesthesia
COAG” setting. Measured load
resistance = 500 Ω
ARC350SCFC_SE_080124_3
010203040
0
500
1000
1500
2000
2500
displayed value
U [Vp]
• Diagram of HF output voltage U [Vp] as
a function of the “Local Anesthesia
COAG” setting (idle mode)
