Treadmill 10:  My treadmill is powered on but the display won't light up
about:blank
2/6
(Reference 2)
Treadmill 22 shown. Your treadmill may vary slightly.
Remove the right base shroud to access the 6-pin connector.
4. If the issue persists, use a Phillips head screwdriver toremove the outer junction cover from the top of the right
upright (reference 3) and inspect the white 6-pinconnector. Unplug the white 6-pin connector and check for damage
to the connector or cable. If undamaged, firmly reconnect the cable, ensuring the connector is oriented properly; the
tabs on top should line up and audibly click into place when firmly connected. Test if the issue persists[11407.G].If
the cable is damaged,order MCB to Top Upright Cables[11407.H].
(Reference 3)
