BRADEN HP35A - Specifications

20
11.9
Low Speed
High Torque
Motor
10.2/5.1
2-Speed
Gear Motor
11.0
Gear Motor
Rated Bare Drum Line Pull
35,000 Lb
(15,905 kg)
35,000 Lb
(15,905 kg)
35,000 Lb
(15,905 kg)
Bare Drum Line Speed - Single Speed
27 fpm
(8 mpm)
57 fpm
(17 mpm)
52 fpm
(16 mpm)
Cable Drum Diameter
6.06 in.
(154 mm)
6.06 in.
(154 mm)
6.06 in.
(154 mm)
Cable Drum Flange Diameter
14.0 in.
(356 mm)
14.0 in.
(356 mm)
14.0 in.
(356 mm)
Distance Between Flanges
12.37 in.
(314 mm)
12.37 in.
(314 mm)
12.37 in.
(314 mm)
Wire Rope Capacity - 3/4" (20 mm)
187 ft.
(57 m)
187 ft.
(57 m)
187 ft.
(57 m)
Overall Gear Ratio
35:1 35:1 35:1
Maximum Pressure
2,578 PSI
(178 Bar)
2,754 PSI
(190 Bar)
2,509 PSI
(173 Bar)
Maximum Flow
30 GPM
(113 lpm)
60 GPM
(227 lpm)
60 GPM
(227 lpm)
Capstan Rating (7" Capstan)
3,200 Lb
(1,450 kg)
N/A N/A
Capstan Speed
185 ft
(56.4 m)
N/A N/A
Winch Weight
650 Lb
(295 kg)
650 Lb
(295 kg)
650 Lb
(295 kg)
- Add for Extension Shaft
90 Lb
(41 kg)
N/A N/A
Gearbox Oil Capacity
10.5 pt
(5.0 L)
10.5 pt
(5.0 L)
10.5 pt
(5.0 L)
Capstan Ratio
5.4:1 N/A N/A
HP35A
SPECIFICATIONS
