BRADEN HP35A - Hydraulic Motor Service; HP35 A Low Speed High Torque Hydraulic Motor

41
HP35A Low Speed High Torque
Hydraulic Motor
1
11
7
8
2
3
5
6
10
9
PORT B
SAE -10 PORT
ITEM NO DESCRIPTION QTY
1 HYDRAULIC MOTOR 1
2 BRAKE VALVE ASSY 1
3 CAPSCREW 3
5 ADAPTER 1
6O-RING 1
7 LOCKWASHER 2
8 CAPSCREW (1/2 - 13 X 1-1/2 G8 Z) 2
9
SWIVEL NUT 90° ELBOW
1
10 ADAPTER 1
11 HOSE ASSY 1
