Brady M211 User Manual

M211 User Manual 1
1 Introduction
Print labels with the Brady Express Labels mobile app and the M211 label printer. The M211 printer
includes the following features:
• Withstands a 6 ft. (1.8 m) drop.
• Crush resistant to 250 lbs (113.4 kg).
• Military-grade shock resistance.
• Uses M21 series print cartridges.
• Automatic label cutter.
• Bluetooth® Low Energy 5.0 enabled.
• Compact and lightweight at 1.2 lbs (0.5 kg).
• Prints 100 labels per day.
• Internal lithium ion battery.
System Specifications
The M211 printer has the following specifications:
• Weight 1.2 lbs (0.54 kg) (with label cartridge).
• Thermal transfer print mechanism, 203 dpi.
• Print width: 0.63" (16 mm) maximum.
• Print length for labels: 36” (914 mm) maximum.
• Liner width: 0.875" (22.2 mm) maximum.
• Label widths from 0.235" (6.4 mm) through 0.75" (19 mm).
• Minimum label height: 0.236" (5.99 mm).
• Prints up to 300 labels per battery charge.
• Print speed: up to 0.6 in/sec (15.2 mm/sec)
• Internal lithium ion battery, 1100 mAh

Brady M211 Specifications

General

Print Technology	Thermal Transfer
Connectivity	Bluetooth
Display	LCD
Print Resolution	203 dpi
Cutter Type	Manual
Max Print Width	0.75 inches
Power Source	Rechargeable Battery
Maximum Label Width	2.25 inches
Print Speed	0.4 inches per second
Label Compatibility	M21 Series Labels
Label Width	0.25 in to 0.75 in
Max Label Length	3 ft
Keyboard	None (uses mobile app)
Memory	No
Supported Materials	Polyester, Vinyl
