ENGLISH 23 / 77 CAP. 5 - GENERAL DESCRIPTION
M
ULTIGAS
5.6 USER INTERFACE
All settings, controls and service functions are available on the touch screen display. It also
displays the service equipment’s status, the progress of A/C system service and any alarms and
error messages.
The touch screen is the basic operator interface and can be operated with the fingers or some
other object, such as a pen.
When a button is pressed, a beep sounds.
The following functions are available:
scroll left: previous menu
scroll up: top menu
scroll down: lower menu
press: confirm / enter
press and hold: open the function to change it or press the ''home'' button
double press: supplementary functions
To select a MENU (e.g. MANUAL CYCLES), press the text MANUAL CYCLES: the selection occurs
when the finger is released, the selected entry is pointed out with a different colour and the menu
screen page changes.
If there are descriptions that need more space on the screen page, for example the manual cycles
list (see the screen page below), or in case of setup, it is possible to display the different entries by
moving the scroll bar to the side. For this reason, it is necessary to touch the grey point on the
scroll bar and slide up or down with the finger.
Lift the finger when you are on the desired position.
By touching the scroll bar once, the menu moves one line up or down depending on whether it is
touched over or under the grey dot.
The “home” icon is the button to “interrupt/return to the main menu’’.
To access to the main menu you have to touch it for 2 seconds. Sliding to the left with the finger
you can access to the previous menu.
