3. Usability Features
The ES industrial range has been designed so that it is as easy as possible to wire up the serial port
and power wires to the terminal blocks and to connect the network cable:
• Removable screw terminal blocks make installation easier and quicker.
• Colour coded terminal blocks and ports prevent an incorrect connection.
• Individually numbered pins simplify the wiring and removes confusion.
• Smart Ethernet which automatically detects the polarity of the Ethernet connection so either a
straight through or crossover Ethernet cable can be used.
• Dual power supply input, for enhanced reliability.
• Functional ground to DIN rail.
