9.3.2 Available Microscope Adapter Kits
Orientation
All illustrations in this section show the microscope tracking array attached to the microscope
adapter:
• In the standard orientation ①
• At a 90° angle ②
Leica M500-N, M520, M525, M530, M720 (SAI) (41767-70)
Figure 61
Haag-Streit Hi-R 1000/Hi-R 700 (41767-85)
Figure 62
MICROSCOPES
Instrument User Guide Rev. 2.6 Cranial/ENT Optical Tracking 107
