4.2 Multiple Tip Pointer Package
General Information
The Multiple Tip Pointer Package (B12201) is available with interchangeable tip geometries,
supporting a wide range of surgical approaches.
Components
Figure 8
Name Tip Length Curved Tip End
Length
Offset Article No.
Handle for Multiple Tip
Pointer
n/a n/a n/a 55791
Pointer Tip
95 mm 20 mm (-70° angle) 30° 55791-03
100 mm 20 mm (-90° angle) 0° 55791-04
123 mm (di-
ameter
3.4 mm)
n/a 0° 55791-34
60 mm n/a 0° 55791-05
150 mm n/a 0° 55791-01
Tip Set for Paint Pointer
①
②
Figure 9
The Tip Set for Paint Pointer is designed for accessing sinus cavities and the tips are available
for use in combination with Paint software features.
No.
Component Article No.
①
Pointer Tip Structure Acquisition (Curved) 55791-06
POINTERS
Instrument User Guide Rev. 2.6 Cranial/ENT Optical Tracking 31
