7 ULTRASOUND
7.1 Ultrasound Adapters
General Information
Ultrasound Adapters allow you to adapt the ultrasound probes to be compatible with Brainlab
navigation software and systems. The adapters are available with various lock mechanisms to fit
specified probes.
NOTE: The probes listed in this user guide may not have been approved for intraoperative
neurosurgical procedures in all countries. Ensure that the intended use of the ultrasound device
and the probe includes intraoperative neurosurgical procedures. See the manufacturer's
instructions for further details on how to use the respective ultrasound device/probe.
Before You Begin
Warning
Before performing navigation, the ultrasound probe must be calibrated using the
Ultrasound Registration Phantom.
Warning
Any movement of the probe independent from the adapter will cause inaccuracy during
navigation, endangering the patient.
Before attaching an adapter to the ultrasound probe, make sure you select the correct
adapter for your probe.
Ultrasound adapters are designed for specific ultrasound probes. If it is difficult to attach
the adapter on the probe check if it is damaged or the correct type. Avoid using heavy
force when attaching the adapter as it could damage the ultrasound probe.
Unique Fit Adapters
Array
Transducer/
Probe
Adapters Fit Article No.
Ultrasound
Navigation
Adapter Array
(22595)
BK Medical
Ultrasound Navigation
Adapter Base
• BK 8862/8863/N11C5S
• BK N13C5
Unique
(recalibration
not required)
• 41860-35
• 41860-40
Ultrasound Navigation
Adapter Base BK X18L5s
41860-43
ULTRASOUND
Instrument User Guide Rev. 2.6 Cranial/ENT Optical Tracking 87
