Opening a Session
Workflows for Data Transfer and Planning
Preplanned Data
To navigate preplanned data, select Planning rather than Data Transfer . Other-
wise, all preplanned data will be lost.
Workflows
NOTE: For information on transferring data using PatXfer , see the PatXfer Clinical User
Guide
. For information on planning cranial or ENT treatments using iPlan , see the relevant
iPlan Software User Guide .
Option Workflow Steps
Transfer patient data via
DICOM and perform naviga-
tion
• Select
Data Transfer to open PatXfer .
•In the
Send to... dialog, export the patient to To
Navigation
.
•
PatXfer closes and the Navigate Now dialog opens.
• To begin navigation, press
Now .
Transfer local patient data and
perform navigation
• Select
Data Transfer to open PatXfer .
•In the
Archive selection dialog, select Local Pa-
tients
.
• Select the patient. In the
Send to... dialog, export
the patient to
To Navigation .
•
PatXfer closes and the Navigate Now dialog opens.
• To begin navigation, press
Now .
Export a preplanned treatment
plan and perform navigation
• Select
Planning to open iPlan .
•In
iPlan , export the treatment plan to the navigation
system.
• Once you exit
iPlan , the Navigate Now dialog
opens.
• To begin navigation, press
Now .
Transfer patient data via
DICOM and perform plan-
ning
• Select
Data Transfer to open PatXfer .
•In the
Send to... dialog, select Local Patients .
• Once you exit
PatXfer , select Planning to open iP-
lan
.
Perform planning on local pa-
tient data
Select
Planning to open iPlan .
Transfer patient data via
DICOM to the local system
• Select
Data Transfer to open PatXfer .
•In the
Send to... dialog, select Local Patients .
