SERIES 70 ELECTRIC ACTUATOR
Installation, Operation, and Maintenance Manual
28 of 48
© 2022 BRAY INTERNATIONAL, INC. ALL RIGHTS RESERVED. BRAY.COM
The Information contained herein shall not be copied, transferred, conveyed, or displayed in any manner
that would violate its proprietary nature without the express written permission of Bray International, Inc.
4. To replace the switch plate:
a Engage handwheel
b Place insert into the worm segment
c Place and center shaft coupler onto insert
d Align indicator shaft with groove in coupler and gently place switch plate into
position
e Check alignment of override switch activation pin
f Slowly turn handwheel to ensure that the indicator shaft is fully engaged in
coupler
g Secure the switch plate with seven Phillips head mounting screws in a “star
pattern
h Disengage the handwheel
5. To remove the indicator shaft from the switch plate:
a Follow after removing the switch plate
b Remove the retaining ring from the shaft located underneath switch plate
c Press the shaft out from the bottom of the switch plate
d NOTE Provide support to top of switch plate so that components on top of
the switch plate are not damaged during this procedure
6. To remove the bearing from the switch plate:
a Follow after the removing the indicator shaft
b Press the bearing from the top of the switch plate to remove the bearing
c To replace press bearing (-) into switch plate from the
bottom of switch plate
7. To replace the indicator shaft in the switch plate:
a Gently press the indicator shaft from the top of the switch plate until the
cams are flush with the top surface of the switch plate NOTE Provide
support for the press fit bearing during this step
b Replace retaining ring (-) on the shaft located underneath
switch plate
c Gently press the indicator shaft from the bottom until the retaining ring is
flush with bottom of the bearing
d Test indicator shaft for tight fitment and ease of rotation
8. Other switch plate components:
a Most components can be removed from the switch plate without removal of
the switch plate
NOTE Override switch assemblies are typically only removable after the switch
plate has been removed A specialty (short or ) screwdriver could be used for
disassembly when the switch plate is still attached to the actuator base
