Brecknell 6702U - Page 39

67XXU USB/Serial Scale Service Manual 39
ZRO.PT IZSM 0-100 10 Initial zero set
mechanism
Range of capacity in percent
± 0 - 100%FS
Also uses SAZSM and AZSM (total)
*If (REGUL)=none, the max is 10
IN.IZS WEGHT WEGHT Inside IZSM WEIGHT= on power up
CAL.ZR CAL.ZR= calibration zero point
LST.Z.T LST.Z.T=store last push button zero
and push button tare
*If (REGUL) ≠none, the value is
fixed on WEIGHT
OV.IZS DP.OVR DP.OVR Outside IZSM DP.OVR=display initial zero is over.
Display will show upper dashes
when above capacity
WEGHT WEIGHT= current weight
Can zero more weight (approx 90%)
before dashes are displayed. Not
Legal for Trade
CAL.ZR CAL.ZR= calibration zero point
will display dashes at 100%
LST.Z.T LST.Z.T=Last ZERO and TARE
SAZSM 0-100 2 Zero key range 0=no limitation
1-100= (initial zero point) ±1%FS -
(initial zero point) ±100%FS
*If (REGUL) ≠none, the max is 2
AZSM 0-100 8 Zero tracking window 0=0d, no tracking
1-100=±(0.2+0.05*(1-100))d /s
*If (REGUL) ≠none, the max is 4
FLTER FT1.TH 0-255 40 Digital filter1 threshold 0=no filter1
1-254=filter1 used only when
vibration in ±0.25d*(1-254)
255= filter1 always used
FT1.ST weak midle Digital filter1 intensity Weak = 4 weights to average
Midle = 8 weights to average
Strong = 16 weights to average
midle
stong
FT2.TH 0-255 8 Digital filter2 threshold 0=no filter2
1-254=filter2 used only when
vibration in ±0.25d*(1-254)
255= filter2 always used
FT2.ST 0-255 240 Digital filter2 intensity 0-255=weak to strong
CONFG
SubMenu1 SubMenu2 Option Default Parameter Description Comment
