67XXU USB/Serial Scale Service Manual 45
COM2
(9 Pin)
BUD.RT 1200 9600 Select COM2 baud rate
2400
4800
9600
19200
38400
BT.FMT 8N1 7e1 Select COM2 byte format (1) 8N1=8 data bits, No parity check
bit, 1 stop bit
7O1 (2) 7O1=7 data bits, 1 Odd parity
check bit, 1 stop bit
7E1 (3) 7E1=7 data bits, 1 Even parity
check bit, 1 stop bit
OUT.MD none PRT.CD Select COM2 output mode (1) NONE=no communication
CONT (2) CONT=continuously output
PRINT (3) PRINT=output after PRINT key
pressed
CMD (4) CMD=output after a request
command is received
PRT.CD (5) PRT.CD= output after PRINT
key pressed or request command
received
STABL (6) STABL=output after scale is
stable; Note: use PRINT or CMD to
output data, the scale must be
stable
st.nld **(7) ST.NLD=output after scale has
returned to zero range and is
stable. (OTHER>NLD.RG)
nld **(8) NLD= Output after scale has
returned to zero range and does not
wait for the scale to be stable.
(OTHER>NLD.RG)
Pr.nLD (9) PR.NLD= Manual push button
print once after scale is stable.
Scale has to return to zero range
(OTHER>NLD.RG) before another
push button print command can be
executed.
**Note: If PRINT, STABL, ST.NLD, LNLD or CMD are used to output data, the scale must be stable.
USER
SubMenu1 SubMenu2 Option Default Parameter Description Comment
