1. Recipe Name: The name of the currently loaded recipe.
2. Load button: Opens the dialog to load a recipe into the editor.
3. Save button: Opens the save dialog for saving the current recipe.
4. Delete button: Opens the delete dialog for deleting recipes.
5. Velocity column: Boxes where velocity (spin speed) values are entered (in rpm) for
each step.
6. Ramp column: Boxes where ramp acceleration values are entered (in rpm/s) for
each step.
7. Time column: Boxes where the length of each step is entered in seconds.
8. Dispenses column: Boxes that allow the user to select which dispenses are active
for each step.
9. Exhaust column: Boxes where the exhaust setting (in a percentage) is selected for
each step. (Programmable exhaust is not available on all models.)
10. Oscillation column: Boxes where the time between oscillations (in seconds) is
entered. (Oscillation mode is not available on all models.)
11. Insert button: Inserts a blank step in front of the currently highlighted step.
12. Delete button: Deletes the currently selected step.
13. Clear All button: Clears all the data loaded in the editor.
14. Scroll Up button: Steps the recipe up one step.
15. Scroll Down button: Steps the recipe down one step.
16. Highlighted step: The currently highlighted step is indicated with a darker gray
color.
