Model 1600:
Model 1800:
18. Pressure Port: When cover is
CLOSED, all steam passes through
this port through the pressure regulat-
ing valve.
19. Capillary Guard: This guard protects
temperature sensor probe, hi-limit bulb
and capillary from damage.
CAUTION: Check oil level before
turning cook/filter switch to COOK.
20. 1600/1800E Hot Oil Level: Indicates
proper level when oil is at operating
temperature. 1800GH: HOT OIL
LEVEL is stamped on capillary guard.
Model 1600:
Model 1800:
21. Exhaust Tank: Steam and vapors are
exhausted through this tank.
22. Filter Pump and Motor: Used to return
oil to cooking well when filtering.
4 - 5
Manual #13897 10/97
