7. After cleaning, completely dry. Lubri-
cate O-ring with clean liquid shorten-
ing. Install O-ring in O-ring groove.
SPLASH SHIELD
WARNING: Allow cover assembly to
cool before cleaning. Hot surfaces
could cause serious burns.
If your unit is equipped with a two piece
splash guard, clean it according to the fol-
lowing instructions:
1. OPEN cover and slide back 2 to 3
inches.
2. Rotate cover handle (1) to a centered
position.
3. Loosen screws (2) attaching back
splash shield (3) to splash shield (4).
4. Slide splash shield (4) forward and up
towards the end of the cover handle
(1).
5. Clean the top and underside of splash
shield and top of the cover.
Note: Make sure back splash shield (3) and
splash shield (4) are assembled correctly
after cleaning. The cover may not close cor-
rectly if they are not.
6. Assemble in reverse order.
Filter Pan & Cover
Wipe all oil off filter pan and both sides of
the filter pan cover.
WARNING: Rags or paper containing cook-
ing oil can catch fire if exposed to heat.
Laundering will not remove the oil. Dis-
pose of all oil-soiled papers and rags in
a trash container that is in a ventilated
area away from all cooking equipment
or other heat sources such as direct
sunlight.
11 - 3
Manual #13897 10/97 Rev 10/11
