3-4
This tab is the filter motor control and has
two buttons; a Start Pump button and a
Alert Silence button.
There are also two reminders to observe
before filtering the oil. SEE SECTION 9 -
COOKING OIL CARE AND FILTERING
before starting the pump motor.
When the Start Pump button is pressed the
filter running display appears as shown
below.
The timer in the middle of the screen starts
counting up. When it reaches 5:00 minutes
an alert sounds and a reminder flashes (see
below) to close the drain valve. To silence
the alert press the button with the speaker
on it. DO NOT press the Stop Pump button.
The pump will continue to run and will auto-
matically stop when the counter says 10:00
minutes. You will see the display below.
To return to the Cook Tab, press the red X in
the upper left corner. The Caution Display
will appear advising the oil level be
checked. If the oil level is OK press the
green OK button.
Stop
Pump
X
Start / Stop Filter Pump
Filter Pump Running
00:00
FILTER TAB
Cook Filter Setup Help
* Check Filter Pan & Components
* Stir Oil Before Opening Drain Valve
Start
Pump
Stop
Pump
X
Start / Stop Filter Pump
Filter Pump Running
00:00
Close Drain Valve
Start
Pump
X
Start / Stop Filter Pump
Filter Pump Run Time
10:00
Limit Reached
broaster.com Manual #17270 10/13 Rev 12/14
