9 - DRAIN VALVE AND FILTER SYSTEM
9-1
DRAIN VALVE
Used to drain oil from cooking well into filter
pan or container made for handling hot oil.
Never drain oil unless pres-
sure regulating valve is
OPEN. Hot oil could spray out under pres-
sure causing serious burns.
Replacement:
1. Disconnect main electric supply.
2. Remove filter pan from under the unit.
Drain cooking oil from cooking well
into a container made for handling hot
oil.
3. Remove nut (1), screw (2) and interlock
(3).
4. Remove nut mounting handle (4) to the
drain valve (5).
5. Remove nipple (7) from drain valve.
6. Unscrew drain valve from the cooking
well (6).
7. Assemble in reverse order using
#15820 Primer & #15359 Sealant on
cooking well threads.
