Pulse Input Time Unit (Time UNIT)
This is the time component for the engineering units of the display values being entered. Enter the
appropriate units/second, units/minute, units/hour, or units/day that corresponds to the values being
entered at the display 1-32 ( dsp) menus.
For example, if the display values are being entered in gallons/second the time unit would be set to
seconds.
Manual Multi-point Entry (INP, DSP)
Manual entry of the linearization data is done once the number of points has been selected (NO PTS).
Input signal levels (InP 1-32) for up to 32 points, along with the desired/corresponding meter reading
(dSP 1-32), should be entered for each linearization point.
Each scale point (1-32) has an input value and a display value. The input value is the number of
pulses/sec (frequency), and the display value is the corresponding display value for that input in the time
unit selected (example: gallons per minute, or GAL/M)
Important Programming Note: Save (save?)
After entering the last display value, the scaling entries must be saved (SAUE?)
before they will be put into effect. However, you may move past this selection
using the Up arrow key if you need to go back and correct an earlier entry. Once
confident in the entries, however, the user must navigate back to the Save menu
screen (SAUE?) and press the Enter key to save the changes.
