Factory Defaults & User Settings
The following table shows the factory setting for most of the programmable parameters on the meter.
Next to the factory setting, the user may record the new setting for the particular application.
Model: ______________ S/N: _______________ Date: _________
Parameter Display Default Setting User Setting
Input Type
INPUT
Active
K-Factor units
FuNiT
Pulses/Gallon
K-Factor
Factr
1.0000
Rate Time Base
Tbase
Second
Rate Unit
RateU
Gallons/second
Total Unit
Tot U
Gallons
Total Multiplier
Nmult
x1
Grand Total Unit
GtotU
Gallons
Grand Total Multiplier
Nmult
x1
Rate Decimal Point
1111.1
1 place
Total Decimal Point
111111.1
1 place
Grand Total Decimal
Point
111111.1
1 place
Total Conversion
Factor
TotCF
N/A (Only valid with
custom units)
Grand Total
Conversion Factor
grtCF
N/A (Only valid with
custom units)
Top Display
TOP
Rate
Bottom Display
BOTNm
Total
Advanced Features
Total Reset
T rst
Manual - Enabled
Grand Total Reset
T rst
Manual - Enabled
Analog Out Value
A out
Rate
Output Display 1
Dspl1
0000.0
Output 1
Out 1
4.000
Output Display 2
Dspl2
1000.0
Output 2
Out 2
20.000
Scale Enable
SCALE
No – Use K-Factor
Scale/Cal # Points
nopts
2 (N/A)
Scale Unit
Funit
Pulses/Gallon (N/A)
Scale Unit Time Base
tinme
Second (N/A)
Scale/Cal Input 1
Inpt1
00000 (N/A)
Scale/Cal Display 1
dspl1
0000.0 (N/A)
Scale/Cal Input 2
Inpt2
1000 (N/A)
