Brother DCP-B7500D Service Manual

2-62
Confidential
 Error code 8E01
Paper size is not set as A4/Letter/Legal/Folio when receiving fax or printing a list/report.
Error code 8E02
Detected that the size of paper set in the paper tray was over 10 mm shorter than paper size
set in the machine during faxing or printing a list or report.
<User Check>
• Set A4 or Letter-size paper.
 Error code 9001
The size of paper loaded in the MP tray and the one specified from the driver are not same
when paper is fed from the MP tray.
Error code 9002
The size of paper loaded in the paper tray and the one specified from the driver are not same
when paper is fed from the paper tray.
<User Check>
• Change the driver setting to be matched with the size of the paper set in the paper tray.
 Error code 9201
When printing from the MP tray, paper type setting in the machine does not match the setting
in the driver.
Error code 9202
When printing from the paper tray, paper type setting in the machine does not match the
setting in the driver.
<User Check>
• Use the same paper type setting for the machine and driver.
Step Cause Remedy
1
Registration rear actuator caught
in some sections of the machine
Reattach the registration rear actuator.
2 Registration rear sensor failure Replace the actuator holder ASSY.
3 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Registration rear actuator caught
in some sections of the machine
Reattach the registration rear actuator.
2 Registration rear sensor failure Replace the actuator holder ASSY.
3 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1 Malfunction of the main PCB Install the latest main firmware.
2 Main PCB failure Replace the main PCB ASSY.

Brother DCP-B7500D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Duplex copying	-
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, File, Image
Input color depth	30 bit
Output color depth	24 bit
Input grayscale depth	10 bit
Output grayscale depth	8 bit
Optical scanning resolution	1200 x 1200 DPI
Faxing	No
Total input capacity	250 sheets
Total output capacity	120 sheets
Paper tray media types	Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 230 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Gray
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.03 W
Power consumption (ready)	42 W
Power consumption (sleep)	6.2 W
Power consumption (printing)	485 W

Weight and Dimensions

Depth	398.5 mm
Width	410 mm
Height	272 mm
