Brother DCP-B7500D Service Manual

2-113
Confidential
4.13 Troubleshooting for FAX/Phone Problems
4.13.1Fax cannot be sent
<User Check>
• Check that the line cord is inserted into the socket correctly.
• Check that the dial function setting (tone/pulse) is correct.
• Check that the fax document is set in the ADF correctly.
• Check that the number to be dialed is saved correctly in the telephone directory.
• Check that the receiver's machine works normally or the function you want to perform is
equipped with the receiver's machine.
• Move the machine to the other place to check whether there is any noise source near the
machine.
• Replace the telephone line.
Step Cause Remedy
1
Connection failure of the
modem flat cable
Reconnect the modem flat cable.
2
Connection failure of the CIS
flat cable
Reconnect the CIS flat cable.
3
Connection failure of the
panel flat cable
Reconnect the panel flat cable.
4
Connection failure of the
touch panel flat cable
Reconnect the touch panel flat cable.
5
Connection failure of the key
PCB flat cable
Reconnect the key PCB flat cable.
6
Connection failure of the ADF
document detection sensor
PCB harness
Reconnect the ADF document detection
sensor PCB harness.
7
Document detection actuator
coming off
Reattach the document detection actuator.
8
First or second side CIS flat
cable failure
Replace the first or second side CIS flat
cable.
9
First or second side CIS unit
failure
Replace the first or second side CIS unit.
10 ADF drive gear failure Replace the ADF unit.
11 Document scanner unit failure Replace the document scanner unit.
12 Panel PCB failure Replace the panel PCB ASSY.
13 Key PCB failure Replace the key PCB ASSY.
14 Modem PCB failure Replace the modem PCB ASSY.
15 Main PCB failure Replace the main PCB ASSY.

Brother DCP-B7500D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Duplex copying	-
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, File, Image
Input color depth	30 bit
Output color depth	24 bit
Input grayscale depth	10 bit
Output grayscale depth	8 bit
Optical scanning resolution	1200 x 1200 DPI
Faxing	No
Total input capacity	250 sheets
Total output capacity	120 sheets
Paper tray media types	Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 230 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Gray
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.03 W
Power consumption (ready)	42 W
Power consumption (sleep)	6.2 W
Power consumption (printing)	485 W

Weight and Dimensions

Depth	398.5 mm
Width	410 mm
Height	272 mm
