Brother DCP-B7500D Service Manual

2-18
Confidential
Error
Codes
Description
Refer
to:
Error
Codes
Description
Refer
to:
0D04 --- 2500
Toner cartridge could not communicate
with the cartridge sensor.
2-51
0E00 --- 2501 ---
1003 --- 2502 ---
1004 --- 2503 ---
1100 --- 2601 ---
1200 --- 2602 ---
1300 --- 2603 ---
1400 --- 2604 ---
1500 --- 2605 ---
1701 --- 2701 ---
1801 --- 2702 ---
1802 --- 2703 ---
1803 --- 2801 ---
1808 --- 2802 ---
1901 --- 2803 ---
1A01 --- 2804 ---
1B01 --- 2805 ---
1C00 --- 2806 ---
1D01 --- 2901 ---
1D02 --- 2902 ---
1D03 --- 2903 ---
1D04 --- 2904 ---
1E01 --- 2905 ---
1E02 --- 2906 ---
1F00 --- 2A01 ---
1F02 --- 2A02 ---
2000 --- 2A03 ---
2001 --- 2B01 ---
2002 --- 2B02 ---
2003 --- 2C01 ---
2100 --- 2C02 ---
2101 --- 2D01 ---
2102 --- 2E00
Could not communicate with the
cartridge sensor on the machine side.
2-51
2103 --- 2E01 ---
2200
Cartridge sensor detected that the
incompatible toner cartridge was
installed.
2-51 2E03 ---
2201 --- 2F01 ---
2202 --- 2F03 ---
2203 --- 3001 ---
2400
Toner cartridge is not recognized by
the cartridge sensor.
2-51 3002 ---
2401 --- 3003 ---
2402 --- 3102 ---
2403 --- 3202 ---

Brother DCP-B7500D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Duplex copying	-
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, File, Image
Input color depth	30 bit
Output color depth	24 bit
Input grayscale depth	10 bit
Output grayscale depth	8 bit
Optical scanning resolution	1200 x 1200 DPI
Faxing	No
Total input capacity	250 sheets
Total output capacity	120 sheets
Paper tray media types	Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 230 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Gray
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.03 W
Power consumption (ready)	42 W
Power consumption (sleep)	6.2 W
Power consumption (printing)	485 W

Weight and Dimensions

Depth	398.5 mm
Width	410 mm
Height	272 mm
