3-22
Confidential
8. DISASSEMBLY FLOW CHART
Disassembly / Reassembly (second)
9.2 Cord hook
5/5
9.3 Back cover
5/5
9.19 Low-voltage power
supply PCB ASSY
20/30
9.4 Outer chute ASSY
5/5
9.7 Fuser cover
5/5
9.10 Document scanner
unit
15/35
9.11 ADF unit
*1
40/65
9.11.3 Document sub tray
25/25
9.13 Panel unit
(For Touch panel models)
20/20
9.14 Panel unit
(For Non-touch panel models)
20/20
9.13.2 Panel PCB ASSY /
NFC PCB ASSY / LCD
35/50
9.13.3 Touch panel ASSY
25/30
9.22 Fan
5/5
9.25 Filter
5/5
9.5 Front cover ASSY /
Support flap
10/10
*8
15/15
*5
9.18 Fuser unit
15/35
9.8 Inner chute ASSY
10/20
9.17 Joint cover ASSY
20/20
9.20 New toner sensor
PCB ASSY
5/5
9.16 Modem flat cable /
Modem PCB ASSY
45/60
9.11.4 Document
separate roller ASSY
5/5
9.15 Panel flat cable / First
side CIS unit / First side
CIS flat cable
35/60
9.23 Toner box relay PCB
ASSY
*4
/MP relay PCB
ASSY
*5
/ Toner box new
PCB ASSY
*4
15/30
9.11.6 Second side CIS
unit / Second side CIS flat
cable
*6
35/60
9.11.5 ADF separation
holder ASSY
5/5
9.35 Eject sensor PCB
ASSY
25/30
9.30 Frame L unit
55/70
*8
60/80
*5
9.36 Registration
front/rear actuator
holder ASSY
50/60
9.37 Paper feed roller
ASSY / Paper feed
sensor PCB ASSY
25/30
9.6 Side cover R
15/15
9.21 HVPS flat cable /
High-voltage power
supply PCB ASSY
10/25
9.27 Roller holder ASSY
5/5
9.9 Side cover L
15/15
9.9 Handset holder
ASSY
*3
5/10
9.26 Wireless LAN
PCB
*7
5/5
9.14.2 Panel PCB ASSY
5/5
9.14.3 LCD
20/20
9.28 Main PCB ASSY
30/40
9.32 Fuser gear
64R/36R
5/5
9.33 Toner sensor PCB
ASSY
*4
25/35
9.31
Paper feed motor /
Paper feed motor flat cable
45/55
9.29 T1 clutch /
Registration clutch
10/20
*8
25/40
*5
9.34 Front cover sensor
25/30
9.12 Document cover
ASSY
*2
25/30
9.11.2 ADF cover ASSY /
Document stopper
10/10
9.9 Speaker harness
ASSY
5/5
9.24 Laser unit flat
cable / Laser unit
15/30
*1
For models with ADF
*2
For models without ADF
*3
For models with Handset
*4
For models with Toner box
*5
For MP models
*6
Only for models with duplex scanning
*7
Only for wireless network models
*8
For manual feed models
