Brother DCP-B7500D Service Manual

5-19
Confidential
1.3.11 Set PC print functions (Function code 43)
<Function>
This function is used to change the settings of the various print functions summarized in the
table below.
<Operating Procedure>
(1) Press the [4], and then the [3] in the initial state of maintenance mode. For models
without keypad, press the [▲] or [▼] to display “MAINTENANCE 43” on the LCD and
press the [OK]. “Manual Feed” is displayed on the LCD.
(2) Press the [▲] or [▼] to display the function you want to change the setting of, and press
the [SET] or [OK].
(3) For fixed parameters (On/Off, etc.), press the [▲] or [▼] to display the setting you want
to apply, and press the [SET] or [OK].
For parameters requiring numerical value entry, use the keypad to enter a numerical
value if the model has it, and press the [SET].
For models without keypad, press the [▲] or [▼] to change the selected number (0 to 9).
(4) When the [X] or [Stop] is pressed, the machine returns to the initial state of maintenance
mode.
 Setting functions
The available functions change depending on the corresponding emulation.
(For the emulation specifications, refer to “1. GENERAL” in Chapter 1.)
<For models with emulation>
LCD Description Set value Default
Common functions
Manual Feed Manual feed setting On/Off Off
Resolution Print resolution 300/600/1,200 dpi 600 dpi
Toner Save Toner save mode setting On/Off Off
Density Print density level -6 to 6 0
Job Cancel
TimeOut
Time until host timeout after
a job is canceled
0 to 255 seconds 4 seconds
Sleep Time Time until engine sleep
mode is entered
0 to 99 minutes 5 minutes
Page Protection Page memory setting Off/LTR/A4/LGL/Auto Off
Emulation Emulation (print language)
setting
Auto/HP/PS Auto
Auto I/F Time Interface open time setting 1 to 99 seconds 5 seconds
Media Type Paper type setting Thin/Plain/Thick/Thicker/
Transparency/Recycled/
Bond/Envelopes/EnvThin/
EnvThick
Plain
or
Thin
Paper Size Image development area
setting
Letter/Legal/A4/Exec/B5/
JISB5/A5/B6/A6/Monarch/
C5/COM10/DL/DLL/A4Long/
Hagaki/Folio
Letter
or
A4
Copies Number of copies 1 to 99 copies 1 copy

Brother DCP-B7500D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Duplex copying	-
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, File, Image
Input color depth	30 bit
Output color depth	24 bit
Input grayscale depth	10 bit
Output grayscale depth	8 bit
Optical scanning resolution	1200 x 1200 DPI
Faxing	No
Total input capacity	250 sheets
Total output capacity	120 sheets
Paper tray media types	Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 230 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Gray
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.03 W
Power consumption (ready)	42 W
Power consumption (sleep)	6.2 W
Power consumption (printing)	485 W
