Brother DCP-B7500D Service Manual

2-83
Confidential
4.3 Troubleshooting for Image Defects
4.3.1 Image defect examples
Fig. 2-15
Light
(2-84)
Faulty registration
(2-85)
Dark
(2-86)
Poor fixing
(2-86)
Completely blank
(2-87)
Image distortion
(2-87)
All black
(2-88)
Dirt on back side of paper
(2-88)
Vertical streaks
(2-89)
Horizontal stripes
(2-90)
White vertical
streaks on
image (2-90)
Faint print
(2-91)
White spots on image
(2-92)
Band
(2-94)
Downward
fogging of solid
color (2-96)
Horizontal lines
(2-96)
Ghost
(2-97)
Fogging
(2-97)
White horizontal
stripes on image
(2-91)
Spots or dirt
(2-93)
