Brother DCP-B7500D Service Manual

2-43
Confidential
3.3 Communication Errors
Code 1 Code 2 Cause Refer to:
10 07 No document set when calling. 4.11.1
10 08 Wrong fax number called. 4.13.1
11 01 No dial tone detected before dialing. 4.13.1
11 02 Busy tone detected before dialing. 4.13.1
11 03 2nd dial tone not detected. 4.13.1
11 05 No loop current detected. 4.13.1
11 06 Busy tone detected after dialing or receiving a call. 4.13.1
11 07 No response from the receiver in sending. 4.13.1
11 08
No response from the remote station in sending Session
Initiation Protocol (SIP).
4.13.3
11 10 No tone detected after dialing. 4.13.1
11 11
No acknowledgement returned after Fax2 net command
was sent.
4.13.1
13 12 Error signal received after Fax2 net command was sent. 4.13.1
16 09 No Cipher registration 4.13.1
17 01
Called using a dial number that cannot be used for the
NGN line (33 digits or longer or non numeric characters).
4.13.2
17 07 No response from the caller in receiving. 4.13.2
1C 01
Detected that access to the NGN line was not authorized.
(T38: 403 Forbidden)
4.13.3
1C 02
No file or folder (directory) found as a result of search via
the NGN line. (T38: 404 Not Found)
4.13.3
1C 03
Remote station does not support the NGN line. (T38: 488
Not Acceptable Here)
4.13.3
1C 04
SIP (Session Initiation Protocol) connection not possible.
(T38)
USW NGN fax setting is OFF or calling attempted before
acquisition of SIP information.
4.13.3
1C 05
Internal error detected in the communication network.
(T38)
4.13.3
1C 06 SIP Server timeout (T38) 4.13.3
1C 08
An error other than
1C01,1C02,1C03,1C04,1C06,1D01,1D02 or 1D04 was
detected.
4.13.3
1D 01 Detected that the NGN line was busy. (T38: 486 Busy) 4.13.3
1D 02
Detected that the NGN line was temporarily unavailable.
(T38: 480 Temporarily Unavailable)
4.13.3
1D 04
Network cable not connected (Link Down detected) or not
connected to the Network. (T38)
4.13.3

Brother DCP-B7500D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Duplex copying	-
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, File, Image
Input color depth	30 bit
Output color depth	24 bit
Input grayscale depth	10 bit
Output grayscale depth	8 bit
Optical scanning resolution	1200 x 1200 DPI
Faxing	No
Total input capacity	250 sheets
Total output capacity	120 sheets
Paper tray media types	Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 230 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Gray
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.03 W
Power consumption (ready)	42 W
Power consumption (sleep)	6.2 W
Power consumption (printing)	485 W

Weight and Dimensions

Depth	398.5 mm
Width	410 mm
Height	272 mm
