Brother DCP-B7500D Service Manual

2-44
Confidential
20 01 Unable to detect flag field. 4.13.3
20 02 Carrier was OFF for 200 ms or longer. 4.13.3
20 03
Abort detected (“1” in succession for 7 bits or more). 4.13.3
20 04 Overrun detected. 4.13.3
20 05 A frame received for 3 seconds or more. 4.13.3
20 06 CRC error in answerback. 4.13.3
20 07 Echo command received. 4.13.3
20 08 Invalid command received. 4.13.3
20 09
Command ignored in document setting or damping-out at
turn-around transmission.
4.13.3
20 0A T5 time-out error 4.13.3
20 0B CRP received. 4.13.3
20 0C EOR or NULL received. 4.13.3
20 0D
Corresponding command not received although the FIF
command sending bit is ON.
4.13.3
20 0E EOR command received. 4.13.3
20 13
Line disconnected without receiving DCN after receiving
the last page.
(After receiving EOP and sending CFR, received BYE
before receiving DCN.) (T38)
4.13.3
32 01
Remote terminal only with V.29 capability in 2,400 or 4,800
bps transmission.
4.13.3
32 02 Remote terminal not ready for polling. 4.13.3
32 10
Remote terminal not equipped with password function or
its password switch is OFF.
4.13.3
32 11
Remote terminal not equipped with or not ready for
confidential mailbox function.
4.13.3
32 12
Remote terminal not equipped with or not ready for relay
broadcasting function.
4.13.3
32 13 No confidential mail in the remote terminal. 4.13.3
32 14
Available memory space of the remote terminal is less
than that required for reception of confidential mails or
relay broad-casting instruction.
4.13.3
32 15
Remote terminal not equipped with Cipher receiving
function.
4.13.3
32 16 Remote terminal not equipped with SEP function. 4.13.3
32 17 Remote terminal not equipped with SUB function. 4.13.3
32 18 Remote terminal not equipped with color function. 4.13.3
40 02 Illegal coding system requested. 4.13.3
40 03 Illegal recording width requested. 4.13.3
Code 1 Code 2 Cause Refer to:

Brother DCP-B7500D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Duplex copying	-
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, File, Image
Input color depth	30 bit
Output color depth	24 bit
Input grayscale depth	10 bit
Output grayscale depth	8 bit
Optical scanning resolution	1200 x 1200 DPI
Faxing	No
Total input capacity	250 sheets
Total output capacity	120 sheets
Paper tray media types	Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 230 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Gray
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.03 W
Power consumption (ready)	42 W
Power consumption (sleep)	6.2 W
Power consumption (printing)	485 W

Weight and Dimensions

Depth	398.5 mm
Width	410 mm
Height	272 mm
