 Error code A000
Image processing was not completed correctly because the number of pixels required for
image processing is insufficient in the scanned second side data.
 Error code A200
The document scanning position sensor detected that the document length was 90 cm or
more during the one-side scanning.
<User Check>
• Use the paper less than A4 size.
• Remove the jammed document.
 Error code A300
The document scanning position sensor has not detected the document passing even after
the document has been fed for the specified time.
<User Check>
• Adjust the document guide to suit the document size.
• Remove the jammed document.
Step Cause Remedy
1
Incorrect correction data for
second side CIS unit
Execute “Set CIS scan area (Function
code 55)”.
2 Second side CIS unit failure Replace the second side CIS unit.
3 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Document scanning position
actuator caught in some sections
of the machine
Reattach the document scanning position
actuator.
2
Document scanning position
sensor failure
Replace the ADF unit.
3 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Foreign object inside the ADF Remove the foreign objects inside the
ADF.
2
Document scanning position
actuator caught in some sections
of the machine
Reattach the document scanning position
actuator.
3
Connection failure of the
document scanning position
sensor harness
Reconnect the document scanning
position sensor harness.
4
Document scanning position
sensor failure
Replace the ADF unit.
5 Main PCB failure Replace the main PCB ASSY.

Brother DCP-B7500D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Duplex copying	-
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, File, Image
Input color depth	30 bit
Output color depth	24 bit
Input grayscale depth	10 bit
Output grayscale depth	8 bit
Optical scanning resolution	1200 x 1200 DPI
Faxing	No
Total input capacity	250 sheets
Total output capacity	120 sheets
Paper tray media types	Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 230 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Gray
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.03 W
Power consumption (ready)	42 W
Power consumption (sleep)	6.2 W
Power consumption (printing)	485 W

Weight and Dimensions

Depth	398.5 mm
Width	410 mm
Height	272 mm
