Brother DCP-B7500D Service Manual

1-6
Confidential
Model
DCP-L2535DW
DCP-L2537DW
HL-L2390DW
DCP-L2550DN
DCP-7190DN
DCP-L2550DW
DCP-L2551DW
DCP-L2551DN
DCP-L2552DN
DCP-7195DW HL-L2395DW
Warm up Time
(From Sleep Mode)
Less than 9 sec. at 73.4F / 50% (23°C / 50%)
Less than 4 sec. at
73.4F / 50%
(23°C / 50%)
Less than 9 sec. at
73.4F / 50%
(23°C / 50%)
Warm up Time
(From Power ON)
Less than 28 sec. at 73.4F / 50% (23°C / 50%)
FPOT
(From Ready Mode
and Standard Tray)
Less than 8.5 sec. at 73.4F (23°C) / 230V
Less than 7 sec. at
73.4F (23°C) /
230V
Less than 8.5 sec.
at 73.4F (23°C) /
230V
FPOT
(From Sleep Mode
and Standard Tray)
Less than 17.5 sec. at 73.4F (23°C) / 230V
Less than 11 sec.
at 73.4F (23°C) /
230V
Less than 17.5 sec.
at 73.4F (23°C) /
230V
Mono Print Speed
(A4/Letter)
Up to 34/36 ppm
(Quiet Mode:
Up to 13/13 ppm)
(DCP-L2535DW)
Up to 30/32 ppm
(Quiet Mode:
Up to 13/13 ppm)
(DCP-L2537DW,
HL-L2390DW)
Up to 34/36 ppm
(Quiet Mode: Up to 13/13 ppm)
Full Color Print
Speed (A4/Letter)
N/A
Mono Duplex Print
Speed (A4/Letter)
16/17 sides per minute
(8/8.5 sheets per minute)
(DCP-L2535DW)
15/15 sides per minute
(7.5/7.5 sheets per minute)
(DCP-L2537DW,
HL-L2390DW)
16/17 sides per minute
(8/8.5 sheets per minute)
Full Color Duplex Print
Speed (A4/Letter)
N/A
Processor 600 MHz
Back up Clock
N/A
Carton Dimensions
(W x D x H)
580 x 517 x 434 mm
22.8" x 20.4" x 17.1"
608 x 517 x 434 mm
23.9" x 20.4" x 17.1"
580 x 517 x 434 mm
22.8" x 20.4" x 17.1"
Machine Dimensions
(W x D x H)
410 x 398.5 x 272 mm
16.1" x 15.7" x 10.7"
410 x 398.5 x 318.5 mm
16.1" x 15.7" x 12.5"
410 x 426.5 x 318.5 mm
16.1" x 16.8" x 12.5"
410 x 398.5 x 272 mm
16.1" x 15.7" x 10.7"
Weight w/ Carton
13.1 kg / 28.9 lb
(HL-L2390DW)
13.4 kg / 29.6 lb
(DCP-L2537DW)
14.8 kg / 32.6 lb
(DCP-L2535DW)
14.4 kg / 31.8 lb
14.4 kg / 31.8 lb
(DCP-L2550DW for US)
14.5 kg / 32.0 lb
(DCP-L2551DN)
14.5 kg / 32.1 lb
(DCP-L2551DW for LTN)
14.7 kg / 32.4 lb
(DCP-L2552DN)
14.8 kg / 32.6 lb
(DCP-L2550DW for ASA)
TBD
(DCP-7190DN,
L2550DW for LTN,
L2551DW for ASA)
15.4 kg / 33.9 lb 13.1 kg / 28.9 lb
Weight w/o Carton,
w/ toner/drum
10.3 kg / 22.7 lb
(DCP-L2537DW,
HL-L2390DW)
11.8 kg / 26.0 lb
(DCP-L2535DW)
11.6 kg / 25.6 lb
11.6 kg / 25.6 lb
(DCP-L2550DW for US,
L2551DW for LTN,
L2551DN, L2552DN)
11.8 kg / 26.0 lb
(DCP-L2550DW for ASA)
TBD
(DCP-7190DN,
L2550DW for LTN,
L2551DW for ASA)
12.1 kg / 26.7 lb 10.3 kg / 22.7 lb
Weight w/o Carton
and toner/drum
9.2 kg / 20.3 lb
(DCP-L2537DW)
9.4 kg / 20.7 lb
(HL-L2390DW)
10.5 kg / 23.1 lb
(DCP-L2535DW)
10.5 kg / 23.1 lb
10.5 kg / 23.1 lb
(DCP-L2550DW for ASA,
L2551DN, L2552DN)
10.7 kg / 23.6 lb
(DCP-L2550DW for US,
L2551DW for LTN)
TBD
(DCP-7190DN,
L2550DW for LTN,
L2551DW for ASA)
11.2 kg / 24.7 lb 9.4 kg / 20.7 lb
Specifications are subject to change without notice.

Brother DCP-B7500D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Duplex copying	-
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, File, Image
Input color depth	30 bit
Output color depth	24 bit
Input grayscale depth	10 bit
Output grayscale depth	8 bit
Optical scanning resolution	1200 x 1200 DPI
Faxing	No
Total input capacity	250 sheets
Total output capacity	120 sheets
Paper tray media types	Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 230 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Gray
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.03 W
Power consumption (ready)	42 W
Power consumption (sleep)	6.2 W
Power consumption (printing)	485 W

Weight and Dimensions

Depth	398.5 mm
Width	410 mm
Height	272 mm
